Description

The SICOM3028GPT is an intelligent all-in-one modular platform that integrates IEEE1588v2, Sync-E, full gigabit, and both Layer 2 and Layer 3 availability, specifically designed to operate seamlessly. Reliable in electrical service substations and climate demanding industrial environments. The SICOM3028GPT supports fiber / copper ports up to 28 gigabits, complies with IEC61850 and IEEE1613 standards. The SICOM3028GPT is a 19-inch 1U rack-mount device and supports one 1U slot and six 0.5U slots offering maximum flexibility for easy expansion.

The SICOM3028GPT supports IEEE1588v2 and synchronous Ethernet protocol with hardware time stamping and supports BC, P2P TC and E2E TC Clock Modes, achieves a timing accuracy of 100 ns. Supports Power Profile and Telecom Profile, and supports many modules for synchronous sync like TimeServer, GPS and IRIG-B etc. The SICOM3028GPT supports many Layer 2 software functions such as Port, VLAN, Multicast, QoS, Fast Redundant Ring, and Layer 3 functions such as VRRP, RIP, OSFP, IGMP and PIM. Supports administration by Console, Telnet, Web and SNMP-based network management software. By expanding the serial server module, the product can provide up to 24 RS232 / 422/485 serial ports.

Today, the product is widely used in smart substations and many other industrial communication systems. The devices carry a 5-year factory warranty.

REQUEST FOR MORE INFORMATION

Characteristics

Multifunction Switch
  • Flexible modular design for easy expansion, supports up to 28 gigabit fiber / copper ports.
  • Supports DT-Ring, DRP, MSTP and VRRP for network redundancy.
  • Supports Layer 3 routing protocols such as RIP and OSPF.
  • Supports IEEE1588v2 and sync accuracy reaches ± 100 ns, supports ITU-TG8261 / G.8262 synchronous Ethernet, and sync accuracy reaches ± 50 ns.
  • Supports TimeServer module, GPS module, IRIG-B module, TMS activation module, and serial server module.
  • Supports IEC61850 MMS management.
  • Supports cable test.
  • Complies with IEC61850-3 and IEEE1613.
  • It has KEMA, CE, FCC, EN50155 / 50121 certifications
REQUEST FOR MORE INFORMATION
Ethernet

Technical specifications

Multifunction Switch Platform

Software functions

 Switching function

Supports VLAN and PVLAN.
Supports port aggregation.
Supports flow control.
Supports broadcast storm suppression.

Redundancy protocol

Supports DT-Ring, DT-Ring , and DT-VLAN and the recovery time<50 ms.
Supports DHP and DRP and the recovery time<20 ms.
Supports RSTP/MSTP and compatible with STP.

Multicast protocol

Supports IGMP snooping.
Supports GMRP.
Supports static multicast.
Supports GOOSE over IP tunnel (receiver)(Web interface doesn't support)

L3 function (part of sub-models support)

Supports ARP proxy
Supports RIPv1/v2.
Supports OSFPv2.
Supports static routing.
Supports VRRP.
Supports IGMP
Supports PIM SM
Supports GOOSE over IP tunnel (sender) (Web interface doesn't support)

Security

Supports IEEE 802.1x.
Supports HTTPS/SSL.
Supports SSH.
Supports SFTP
Supports RADIUS.
Supports TACACS .
Supports user grading.
Supports MAC address binding.
Supports port isolate.

Service quality management

Supports ACL
Support 802.1p(CoS),DSCP
Supports SP and WRR queuing.

Management and maintenance

Supports Console, Telnet, and Web management methods.
Supports SNMPv1/v2c/v3 and can managed by Kyvision.
Supports IEC61850 MMS management.
Supports file transfer and software update over FTP and TFTP.
Supports the IP/MAC address conflict alarm, power failure alarm, power alarm, temperature alarm, port linkdown alarm, port traffic alarm, CRC and packet lose alarm, CPU alarm, memory alarm, Sfp port rx power alarm, transceiver alarm and ring alarm (Web interface doesn’t support address conflict alarm. Sfp port rx power alarm, transceiver alarm need supported by hardware).
Supports port mirroring.
Supports cable test.
Supports loop detection
Supports CRC protection
Supports Syslog.
Supports RMON
Supports LLDP.
Supports Link-check.
Supports NTP and SNTP.
Supports RTC.

IP address management

Supports Bootp.
Supports DHCP server/client.
Supports Up to 16 different IP addresses and VLAN for system management

Time synchronization (part of sub-models support

Supports PTPv2 (IEEE1588-2008).
Supports Power profile (C37.238).
Supports Telecom profile (in special version).
Supports synchronous Ethernet (ITU-T.G.8261/G.8262).
Supports TMS function.

Product Specifications

Standard

IEEE 802.3i (10Base-T)
IEEE 802.3u (100Base-T)
IEEE 802.3ab (1000Base-T)
IEEE 802.3ad (port aggregation)
IEEE 802.3z (1000Base-SX/LX)
IEEE 802.3x (flow control)
IEEE 802.1p (priority)
IEEE 802.1Q (VLAN)
IEEE 802.1w (RSTP)
IEEE 802.1s (MSTP)
IEEE 802.1x
IEEE1588-2008 (PTPv2)
ITU-T.G.8261/G.8262 (synchronous Ethernet)

Switch properties

Priority queue: 8
Number of VLANs: 4K
VLAN ID: 1–4093
Number of multicast groups: 256
Routing table: 8K (L2 chassis do not involve)
MAC table: 16K
Packet buffer: 12Mbit (SICOM3028GPT-L3F/L3FT/L3G/L3GT), 8Mbit (SICOM3028GPT-L2F/L2FT/L2G/L2GT)
Packet forwarding rate: 41.7Mpps (SICOM3028GPT-L2G/L2GT/L3G/L3GT), 9.5Mpps (SICOM3028GPT-L2F/L2FT/L3F/L3FT)
Switching delay: < 10 μs
Jumbo Frame Size: 10 KB

Interface

Console port: Mini USB, RJ45
Alarm contact: 3-pin 5.08mm-spacing plug-in terminal block, 250 VAC/220 VDC Max, 2 A Max, 10A@1s, 60 W Max
Slots for module: 1U: 1, 0.5U: 6

LED

LED on front panel
Alarm LED: Alarm
Running LED: Run
Ring Role LED: Ring
Synchronization finish LED: Lock
Power LED: PWR1, PWR2
Port LED: Link/ACT
Port speed LED: Speed
LED on rear panel
Port LED: Link/ACT
Port speed LED: Speed

Power Requirements

Power input:
24VDC (18-36 VDC)
48VDC (36-72 VDC)
100-240VAC,50/60Hz;110-220VDC (85-264VAC/77-300VDC)
Power terminal: 5-pin 5.08 mm-spacing plug-in terminal block
Power consumption: < 40 W
Overload protection: Support
Reverse connection protection: Support
Redundancy protection: Support
Hot Swappable: Support

Physical Characteristics

Housing: Metal
Cooling: Natural cooling, fanless
Protection Class: IP40
Dimensions(W×H×D)： 482.6 mm × 44 mm × 359.7 mm (19×1.73×14.16 in.)
Weight: < 10 Kg (22.046 pound)
Mounting: 19 inch 1U rack mounting

Environmental limits

Operating temperature: -40°C to +85°C (-40°F to 185°F)
Storage temperature: -40°C to +85°C (-40°F to 185°F)
Ambient Relative Humidity: 5% to 95% (non-condensing)

Quality assurance

MTBF:
360000h (SICOM3028GPT-L2F/L2G)
359000h (SICOM3028GPT-L2FT/L2GT)
371000h (SICOM3028GPT-L3F/L3G)
368000h (SICOM3028GPT-L3FT/L3GT)
Warranty: 5 years

Approvals

KEMA: Models with power supply of HV:100-240VAC,50/60Hz;110-220VDC
CE: All models
FCC: All models
EN50155: Models with power supply of HV:100-240VAC,50/60Hz;110-220VDC

Industry standard

EMI
FCC CFR47 Part 15, EN55022/CISPR22, Class A

EMS
IEC61000-4-2(ESD) ±8 kV (contact), ±15 kV(air)
IEC61000-4-3(RS) 10 V/m (80 MHz-2 GHz)
IEC61000-4-4(EFT) Power Port: ±4 kV; Data Port: ±2 kV
IEC61000-4-5(Surge) Power Port: ±2 kV/DM, ±4 kV/CM; Data Port: ±2 kV
IEC61000-4-6(CS) 3 V (10 kHz-150 kHz); 10 V (150 kHz-80 MHz)
IEC61000-4-8 (power frequency magnetic field) 100 A/m(cont.), 1000 A/m(1s-3s)
IEC61000-4-9 (pulsed magnetic field) 1000 A/m
IEC61000-4-10 (damped oscillation) 100 A/m
IEC61000-4-12 (oscillatory wave) 2.5 kV/CM, 1 kV/DM
IEC61000-4-16 (common mode conduction) 30 V(cont.), 300 V(1s)

Machinery
IEC60068-2-6 (vibration)
IEC60068-2-27 (shock)
IEC60068-2-32 (free fall)

Location information
